1st Machining Line
Heavy processing equipment
This line is for heavy, precision machining product line. Representative items: Diaphragm for Steam Turbine, Blade ring for Gas turbine.
1st Machining Line
Equipment | Model | Specifications | Count | Maker |
---|---|---|---|---|
CNC HBM | DBC 130CX | 3000 × 2000 × 1600 | 2 | DOOSAN |
CNC VBM | V5000 | Φ5600 × 800 | 1 | BEATHIEZ |
CNC VBM | KOAOMHA 3TC | Φ5000 × 1200 | 1 | SIEMENS |
CNC VBM | OM TMS-20/40 | Φ4000 x 1500 | 1 | O-M |
CNC VBM | NT-25/30 | Φ2500 x 2000 | 1 | HNK |
CNC VBM | TMC-20S | Φ2000 x 1000 | 1 | TOSHIBA |
CNC VBM | ST 16/22 | Φ1600 × 2200 | 1 | S&T Dynamics |
CNC LATHE | YAZAKI | Φ1600 x 10000 | 1 | SHODA |
LAYOUT M/C | TECHAN | 3000 x 2000 x 15000 | 1 | TOKYO BOEKI |
DRILL MASTER | SMDC-40/30VG | 4000 x 3000 x 500 | 1 | SHINIL |
2nd Machining Line
Small and medium-sized processing equipment
This line is for seal ring for gas turbine and steam turbine.
2nd Machining Line
Equipment | Model | Specifications | Count | Maker |
---|---|---|---|---|
CNC VBM | TVL-160 | Φ1600 × 900 | 4 | S&T Dynamics |
CNC VBM | TM2-10N | Φ1400 × 800 | 3 | OM |
CNC VBM | TVL- 120V | Φ1200 × 600 | 4 | S&T Dynamics |
CNC VBM | TSN-10A | Φ1000 x 600 | 1 | TOSHIBA |
NC Milling | NC Milling | TABLE : 400 × 1800 | 1 | Giheung |
NC Milling | TNMU-5 | 1200 X 500 | 2 | S&T Dynamics |
PUNCHING MACHINE | MCU-100N | 500 × 150 | 2 | System Management Code |
LAYOUT M/C | FUSECO | 3000 × 200 × 15000 | 5 | Dongmin Industry |
3rd Machining Line
Machining center
This line is MCT line for machining the vane and blade and nozzle etc..
3rd Machining Line
Equipment | Model | Specifications | Count | Maker |
---|---|---|---|---|
5 Axis MCT | VERIAXIS 730-5X | 730 × 850 × 560 | 1 | MAZAX |
5 Axis MCT | NTX 2000/1500S | 5466 x 2980 x 2626 | 1 | MORI SEIKI |
5 Axis MCT | INTEGEREX 200-Ⅲ STROKE | 580 × 160 × 1045 | 1 | MAZAX |
5 Axis MCT | INTEGEREX 200-Ⅳ STROKE | 580 × 160 × 1045 | 1 | MAZAX |
MCT 4SP(4 SPINDLE) | TBX5-4SP STROKE | 500 × 600 | 1 | BK-ENG |
High-speed machine | MV865 | 800 x 600 | 1 | HANS |
Electrical discharge machine | HQ540K | 500 x 400 x 300 | 1 | HANQI |
MCT | MYNX 6500/50 | TABLE : 600 × 1600 | 5 | DOOSAN |
MCT | KIA VA-50 | TABLE : 500 × 1700 | 1 | KIA |
MCT | WIA KV60N | TABLE : 600 × 1600 | 2 | WIA |
CENTER M/C | GIFU | 800L | 1 | YoungDong technology |
WIRE CUT | EXCETEK V85 | 800 x 500 | 2 | EXCETEK |
Total count
Equipment | Total count | Equipment | Total count | Equipment | Total count |
---|---|---|---|---|---|
CNC VBM | 18 | CNC Lathe | 1 | CNC HBM | 2 |
5 Axis MCT | 4 | MCT | 11 | NC Milling | 3 |
Wire Cut | 2 | MCT 4SP(4 SPINDLE) | 1 | Center M/C | 1 |
Layout M/C | 6 | PUNCHING MACHINE | 2 | DRILL MASTER | 1 |
High-speed machine | 1 | Electrical discharge machine | 1 | ||
